Six-button Smart Switch DALI-2 Wired and Wireless
Order code: zc-ss-6sw-wht
Smart switch with 6 DALI-2 programmable back lit buttons to suit 84 mm wall mount.
Supports both DALI-2 wired and wireless applications.
Features
-
2 mA DALI line current
-
Up to 63 units per DALI line
-
Black and white finishes available
-
Tactile buttons for user accessibility
-
Replaceable buttons with customisable printing
-
Used on wired and wireless DALI networks
-
Selectable button actions on DALI-2 application controller
- Configurable LED status buttons
- Can work as a stand alone system
- In-built temperature sensor that can be monitored through the BACnet and MQTT interface
Dimensions
| Fixing centres | 84 mm |
| Mounting |
Fits on standard C-clip bracket |
| Dimensions | W 75mm / H 117mm / D 34mm |
Wiring Notice
-
The DALI line is not SELV. It must be treated like LV mains
and treated with the same precautions and wiring regulations. -
This product is not bus powered and requires the 240V supply to be connected
Specifications
| Supply | 220 - 240V 50Hz |
| Class | II |
| Control system |
Wired: DALI-2 |
| WIreless: IEC62386-104 over Thread | |
| Radio support |
IEEE 802.15.4 |
| Frequency ban |
2.4 GHz |
| Max radio tx power |
+8 dBm |
| DALI line current |
2mA |
| Wiring |
0.5 - 2.55 mm2 Strip 7 mm |
| Operating temperature |
0 to 55°C |
| Material |
PC UV Stabilised, toughened glass, alumnium |
| Ingree protection |
IP20 |
| Compliance Standards |
IEC 60669-2-1 CISPR 15 IEC 62386-301 EMC-2004/108/EC LVD-2006/95/EC IEC 62386-104 |
Configuration Options
Standalone Wired or Wireless
The smart switches can be used on a standalone DALI-2 network, or a standalone wireless bluetooth network for small configurations and simple systems. Configure button functionality and status colour via bluetooth smart phone.
Wired 101 mode
The smart switch can be wired to a DALI-2 wired network as a DALI-2 switch. Button functionality and LED status colours are programmed through a central head end.
Enabled after a 101 DALI-2 power supply has been connected to the DALI terminal and the device has not been added to a wireless 104 application controller.
Wireless control system as a switch input 104 mode
Similar to wired mode, but without cables. Connect to a wireless application controller and configure button functionality and LED status colours through a central head end.
104 mode is enabled after the device has been added to a 104 application controller such as zc-iot-fc.
Wireless control system as a bridge 104 + 101 mode
The same functionality as a the wireless system, however with the ability to connect wired DALI-2 devices to the switch and have those DALI-2 devices appear and be programmed on the wireless network.
104 + 101 bridge mode is enabled after the device has been added to a 104 controller and a 101 power supply has been connected to the DALI terminals.
