zencontrol
Wireless DALI Bridge
Order code: zc-iot-bridge
Product range |
|
| Order code | Description |
|---|---|
| zc-iot-bridge | Wireless bridge |
Features
- Powered from DALI line
- Protected against DALI over-voltage
- Supports IEC 62386-104 over Thread
- Smart sensor and switch attachments
- Compact form factor for easy integration
- Compatible with DALI and DALI-2 devices
- A wireless control system solution for D4i
- Converts DALI ECGs and ECDs to a wireless system
Specifications |
|
| Supply voltage | 9.5 – 22.5 V (DALI line) |
|---|---|
| Control system | IEC62386-104 over Thread |
| DALI line current | 40 mA |
| Wiring | 0.2 – 1.5 mm2 (DALI) 0.2 – 0.5 mm2 (accessories) Strip 8 – 9 mm |
| Operating temperature | 0 to 60°C |
| Material | PC |
| Classification | Class II |
| Mounting | Inbuilt |
| Ingress protection | IP20 |
| Compliance standards | IEC 61558-2-11 IEC 60950-1 CISPR 15 CISPR 22 EN 55015 EN 55022 IEC 62386-103 Ed 2.0 IEC 62386-104 |
Accessories range |
|
| Order code | Description |
|---|---|
| zc-fm-kit | Field mount kit |
| zc-pir-nano+ | PIR Nano+ sensor, accessory kit |
| zc-rotary-kit | Rotary 20 x 20 mm, accessory kit |
| zc-rotary-2550-kit | Rotary 25 x 50 mm, accessory kit |
| zc-rotary-2550-b-kit | Black rotary 25 x 50 mm, accessory kit |
| zc-pbs-2020-kit | Illuminated pushbutton switch 20 x 20 mm, accessory kit |
| zc-pbs-2550-wh-kit | Illuminated pushbutton switch 25 x 50 mm, white, accessory kit |
| zc-pbs-2550-st-kit | Illuminated pushbutton switch 25 x 50 mm, stainless brushed, accessory kit |
