DALI-2 Illuminated Push Button switch (Mech Only)

Request Pricing Access
Order code: zc-pbs-2020-kit
Sign up to Purchase

DALI-2 Illuminated Push Button switch mechanism to suit 30mech switch plates.

* Mech ONLY *

For use with zc-iot-bridge, zc-switch & zc-switch pro

Do not connect directly to DALI bus!

The simple and intuitive zencontrol push-button gives you control. With the zencontrol control system you can press for on/off and press and hold for dimming brightness


  • DALI bus powered
  • Configurable LED indicator
  • Compliant to IEC 62386-301
  • For use with DALI-2 compliant application controller
  • zc-switch for direct connection to DALI line
  • Suitable for one DALI line of up to 32 devices per DALI line
  • Control scenes / groups / actions / events with a zencontrol control system


Supply DALI
Control system DALI-2
LED indicator colour Royal blue
DALI line current 5 mA
Wiring 0.5 – 0.75 mm2
Strip 6 – 7 mm
Operating temperature 0 to 45°C
Material PC
Ingress protection IP20
Compliance standards IEC 61347-2-11
IEC 62386-301
