4 Channel DALI Blind Relay Controller, 2 x SPST + 2 x SPDT

Request Pricing Access
Order code: zc-relay-2d2s-pro
Sign up to Purchase
Order code Description
zc-relay-2d2s-pro DALI Blind Relay Controller, 2 x SPST + 2 x SPDT



Features

  • 4x Relay output
    • 2 x SPST relay output 10A/492A inrush
    • 2 x SPDT NO/NC relay output 10A
  • 8x 0-10v outputs (IEC62386-205) or 8x digital inputs (IEC62386-301/302/303)
  • Compliant to IEC 62386-208
  • For use with DALI control system
  • Can be designed into wired or wireless systems
  • LED indicators for system status
  • Reinforced insulation between DALI and mains supply
  • Protected against DALI over voltage
  • Suitable for distribution board mounting on standard DIN rail
  • Mains rated dry-contact volt-free relay output
  • Compliant DALI device type 7
  • Compliant DALI device, refer to dali-ag.org


Specifications

Supply voltage 220-240V ~ 50 Hz
Control system Wired DALI-2   Wireless IEC62386-104 over Thread
DALI line current 2 mA
Output load per channel 10 A resistive
6 A inductive
Output type Dry-contact volt-free relay
Max. in-rush 160 A  20ms
Relay type Non-latching normally open
Wiring 1 – 4 mm2
Strip 6 – 7 mm
Operating temperature 0 to 55°C
Material PC
Classification Class II
Mounting DIN rail (35 mm)
Ingress protection IP20
Compliance standards

IEC 61347-2-11
IEC 60950-1
CISPR 15
CISPR 22
EN 55015
EN 55022
IEC62386-205
IEC62386-208
IEC62386-301/302/303
EMC-2004/108/EC
LVD-2006/95/EC
