zencontrol
DALI High Current Relay
Order code: zc-relay-hc
| Order code | Description |
|---|---|
| zc-relay | DALI 16 Amp volt-free relay, DIN mount |
Features
- Large In-rush current tolerance
- For use with all DALI control system
- Compatible with DALI and DALI version 2
- Compliant to IEC 62386-208
- Protected against DALI over voltage
- Suitable for switchboard mount on standard DIN rail
- Mains rated dry-contact volt-free relay output
- Compliant DALI device type 7
- Compliant DALI device, refer to dali-ag.org
Specifications |
|
| Supply voltage | 230 V ~ 50 Hz |
|---|---|
| Control system | DALI |
| DALI line current | 2 mA |
| Output load |
16 A resistive 8 A inductive |
| Output type | Dry-contact volt-free relay |
| Max. in-rush |
165 A 20ms |
| Min. rated relay operations | 12 000 |
| Max. operations per hour | 360 |
| Relay type | Non-latching normally open |
| Wiring | 1 – 4 mm2 Strip 6 – 7 mm |
| Operating temperature | 0 to 45°C |
| Material | PC |
| Classification | Class II |
| Mounting | DIN rail (35 mm) |
| Ingress protection | IP20 |
| Compliance standards | IEC 60669-2-1 CISPR 15 EN 55015 IEC 62386-208 EMC-2004/108/EC LVD-2006/95/EC |
