240V Standalone Microwave Smart Sensor 8m with inbuilt relay and 1 switch

Request Pricing Access
Order code: zc-mw-st-1sw-r
Sign up to Purchase

Features

  • PIR motion sensor
  • Light level measurement
  • Programmable via IR remote
  • IP65 weatherproof rating with mounting accessory
  • Switch inputs for switch models
Programmable features (IR)
  • Sensor time-out
  • Lux level, dusk (if under lux level, activate sensor)
  • Lux level, disable (if over lux level, disable sensor)
Programmable features (switch)
  • Switch type ( on / off, absence)
  • Switch actions (enable / disable sensor, enable / disable lux)

Specifications

Supply 220 – 240 V ~50 Hz
Supply current < 0.1 A
Relay output

120 A / 20 ms inrush current
10 A inductive
6 A resistive
Sensors Microwave, IR, lux
Microwave 5.8 GHz, 0.2mW
IR 38 kHz
Wiring 2.5 mm2 cable (no earth, suits round and tps)
Operating temperature 0 to 55°C
Material PC (body)
Ingress protection IP54 (front-face only)
IP65 (with surface or wall mount kit)
Mounting
(kits sold separately)
Recessed (cut-out min Ø83 mm)
Wall mount kit (mounting centres 85 mm)
Surface mount kit
Rod mount kit
Conduit mount kit (mounting centres 50 – 60 mm)
Compliance standards IEC 61347-2-11
IEC 60669-2-1
CISPR 15
EN 55015

Detection pattern

Range 8 m (mounted at 2.7 m)
Mounting height 2 – 12 m
