ReadyToGo - Tuneable White Dimmer Solution

$414.22 ex-GST

7 units on hand (additional stock available at secondary warehouse)
Order code: lrr-smart-rot-wd-wht

Ready To Go for your project. Introducing the Tuneable White Dimmer Solution. Designed to provide simple, effective control of DALI Device Type 8 (tuneable white) lighting. Using the included Smart Rotary Switch, users can switch, dim, and adjust colour temperature from a single intuitive interface.

Available in both wireless and wired configurations, the solution offers flexible control options suitable for both retrofit and new installations.

No programming is required; simply wire the DALI luminaires as specified, power the system, and it is ready to operate.

The wireless kit supports control of up to 15 tuneable white DALI luminaires, while the wired kit supports up to 30 luminaires before additional DALI power is required. Easily expand by adding extra rotaries or additional DALI power supplies.


Wired kit includes:

  • Wired Tuneable White Smart Rotary Switch
  • DALI Power Supply
  • Field Mount Enclosure

Wireless kit includes:

  • Wireless Tuneable White Smart Rotary Switch
  • Wireless DALI Bridge
  • DALI Power Supply
  • Field Mount Enclosure



Features

  • Wireless or wired control of DALI Device Type 8 (tuneable white) luminaires
  • Press to toggle on/off, hold to dim, rotate to adjust colour temperature
  • LED indicator reflects the current status and colour of the lighting
  • No programming required; wire, power on, and go
  • Wireless kit supports up to 15 DALI luminaires; wired kit supports up to 30
  • Easily expand with additional smart rotaries or DALI power supplies
  • Available in white or black to suit standard switch plates
  • No Wi-Fi or control system required
Supply Voltage 240 VAC
DALI Device Type Device Type 8 (Tuneable White)
Max Luminaires — Wired Up to 30 DALI luminaires
Max Luminaires — Wireless Up to 15 DALI luminaires
Communication Wired DALI / Wireless DALI
LED Indicator Yes — reflects status and colour temperature
Operating Temperature 0 to 45°C
Ingress Protection IP20
Material Polycarbonate (PC)
Intended Use Indoor

For more information, click on the Datasheet below.
